Parameters
9-93 Changed Parameters (4)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter shows a list of all the frequency
*
9-94 Changed Parameters (5)
Array [116]
No LCP Address
Read only
Range:
6 6
0 [0 - 9999 ] This parameter shows a list of all the frequency
*

6.4 Parameter Group 12-** Ethernet

6.4.1 12-0* IP Settings
12-01 IP Address
Range:
0 [0 - 4294967295 ] Configure the IP address of the option.
*
12-02 Subnet Mask
Range:
0 [0 - 4294967295 ] Configure the IP subnet mask of the
*
12-03 Default Gateway
Range:
0 [0 -
*
4294967295 ]
12-04 DHCP Server
Range:
0 [0 - 2147483647 ] Read-only. Show the IP address of the
*
12-05 Lease Expires
Range:
Size related
*
32
Function:
converter parameters deviating from default
setting.
Function:
converter parameters deviating from default
setting.
Function:
Read-only, if parameter 12-00 IP Address
Assignment is set to DHCP or BOOTP.
Function:
option. Read-only, if parameter 12-00 IP
Address Assignment is set to DHCP or
BOOTP.
Function:
Configure the IP default gateway of the
option. Read-only, if parameter 12-00 IP
Address Assignment is set to DHCP or
BOOTP. In a non-routed network, this
address is set to the IP address of the I/O
device.
Function:
found DHCP or BOOTP server.
Function:
[ 0 - 0] Read-only. Show the lease time left for
the current DHCP-assigned IP address.
Danfoss A/S © 04/2017 All rights reserved.
PROFINET
12-06 Name Servers
Range:
0 [0 - 4294967295 ] IP addresses of domain name servers.
*
12-07 Domain Name
Range:
0 [0 - 48 ] Domain name of the attached network. Can be
12-08 Host Name
Range:
0 [0 - 48 ] Logical (given) name of option.
*
12-09 Physical Address
Range:
0 [0 - 17] Read-only. Shows the physical (MAC) address of the
*
6.4.2 12-1* Ethernet Link Parameters
Apply to the whole parameter group.
Index [0] is used for port 1, and index [1] is used for port
2.
12-10 Link Status
Read-only. Shows the link status of the Ethernet ports.
Option:
[0]
*
[1]
12-11 Link Duration
Range:
Size related
12-12 Auto Negotiation
Option: Function:
[0] Off Link Speed and Link Duplex can be configured in
Function:
Can be automatically assigned when
using DHCP.
Function:
automatically assigned when using DHCP network.
Function:
NOTICE
The display of the frequency converter only
shows the first 19 characters, but the
remaining characters are stored in the
frequency converter. If hardware switches
are different from all ON or all OFF, the
switches have priority.
Function:
option.
Function:
No Link
Link
Function:
[ 0 - 0] Read-only. Shows the duration of the
*
present link on each port in dd:hh:mm:ss.
Configure auto negotiation of Ethernet link
parameters, for each port: ON or OFF.
parameter 12-13 Link Speed and parameter 12-14 Link
Duplex.
