Parameters
6.2.2 8-1* Ctrl. Word Settings
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed are visible in the LCP display.
For guidelines in selection of [0] Frequency converter profile and
[1] PROFIdrive profile, refer to the design guide for the frequency
converter.
Option:
[0] FC profile
*
[1] PROFIdrive profile
8-14 Configurable Control Word CTW
Option:
[0] None
[1] Profile default
*
[2] CTW Valid, active low
[4] PID error inverse
[5] PID reset I part
[6] PID enable
8-19 Product Code
Range:
Size [0 -
related 2147483647]
*
6.2.3 8-5* Digital/Bus
Parameters for configuring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Select the trigger for the coasting function.
Option: Function:
[0] Digital input A digital input triggers the coasting function.
[1] Bus A serial communication port or the fieldbus
triggers the coasting function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the coasting function.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the coasting function.
MG06G102
Programming Guide
Function:
Function:
Function:
Select 0 to read out the actual
fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Danfoss A/S © 04/2017 All rights reserved.
8-51 Quick Stop Select
Select the trigger for the quick stop function.
Option: Function:
[0] Digital input A digital input triggers the quick stop
function.
[1] Bus A serial communication port or the fieldbus
triggers the quick stop function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the quick stop function.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the quick stop function.
8-52 DC Brake Select
Select control of the DC brake via the terminals (digital input)
and/or via the fieldbus.
Option: Function:
NOTICE
When parameter 1-10 Motor Construction
is set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
[0] Digital input Activate a start command via a digital input.
[1] Bus Activate a start command via the serial
communication port or fieldbus option.
[2] Logic AND Activate a start command via the fieldbus/serial
communication port and also via 1 of the
digital inputs.
[3] Logic OR Activate a start command via the fieldbus/serial
communication port or via 1 of the digital
inputs.
8-53 Start Select
Select the trigger for the start function.
Option: Function:
[0] Digital input A digital input triggers the start function.
[1] Bus A serial communication port or the fieldbus
triggers the start function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the start function.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the start function.
8-54 Reversing Select
Select the trigger for the reversing function.
Option: Function:
[0] Digital input A digital input triggers the reversing function.
[1] Bus A serial communication port or the fieldbus
triggers the reversing function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the reversing function.
6 6
