Mains Supply; Motor Output And Motor Data - Danfoss VLT Refrigeration Drive FC 103 Design Manual

Specifications
4) Efficiency measured at nominal current. For energy efficiency class, see chapter 7.4 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyefficiency.
5) Measured using 5 m screened motor cables at rated load and rated frequency.
6) Enclosure sizes A2+A3 can be converted to IP21 using a conversion kit. See also chapter 3.7 Mechanical Planning.
7) Enclosure sizes B3+B4 and C3+C4 can be converted to IP21 using a conversion kit. See also chapter 3.7 Mechanical Planning.

7.2 Mains Supply

Mains supply
Supply terminals
Supply voltage
Supply voltage
Supply voltage
Mains voltage low/mains drop-out:
During low mains voltage or a mains drop-out, the frequency converter continues until the DC-link voltage drops below the
minimum stop level. The minimum stop level corresponds typically to 15% below the frequency converter's lowest rated supply
voltage. Power-up and full torque cannot be expected at mains voltage lower than 10% below the frequency converter's lowest
rated supply voltage.
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤7.5 kW
Switching on input supply L1, L2, L3 (power-ups) 11–75 kW
Switching on input supply L1, L2, L3 (power-ups) ≥90 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 240/500/600/690
V maximum.

7.3 Motor Output and Motor Data

Motor output (U, V, W)
Output voltage
Output frequency (1.1–90 kW)
Switching on output
Ramp times
1) From software version 1.10 the output frequency of the frequency converter is limited to 590 Hz. Contact the local Danfoss
partner for further information.
Torque characteristics
Starting torque (constant torque)
Starting torque
Overload torque (constant torque)
1) Percentage relates to the nominal torque.
MG16G202
Design Guide
Danfoss A/S © 08/2015 All rights reserved.
200–240 V ±10%
380–480 V ±10%
525–600 V ±10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥0.9 nominal at rated load
Near unity (>0.98)
Maximum 2 times/minutes
Maximum 1 time/minute
Maximum 1 time/2 minutes
Overvoltage category III/pollution degree 2
0–100% of supply voltage
Maximum 110% for 60 s
Maximum 135% up to 0.5 s
Maximum 110% for 60 s
L1, L2, L3
7 7
1)
0–590 Hz
Unlimited
1–3600 s
1)
1)
1)
