Danfoss VLT Refrigeration Drive FC 103 Design Manual page 131

Specifications
7.8.2 UL Compliance
3x200–240 V
Power Bussmann
[kW]
Type RK1 1)
1.1 KTN-R-10
1.5 KTN-R-15
2.2 KTN-R-20
3.0 KTN-R-25
3.7 KTN-R-30
5.5/7.5 KTN-R-50
11 KTN-R-60
15 KTN-R-80
18.5–22 KTN-R-125
30 KTN-R-150
37 KTN-R-200
45 KTN-R-250
Table 7.12 3x200–240 V, Enclosure Types A, B, and C
Power [kW]
SIBA Littelfuse
Type RK1 Type RK1
1.1 5017906-010 KLN-R-10
1.5 5017906-016 KLN-R-15
2.2 5017906-020 KLN-R-20
3.0 5017906-025 KLN-R-25
3.7 5012406-032 KLN-R-30
5.5/7.5 5014006-050 KLN-R-50
11 5014006-063 KLN-R-60
15 5014006-080 KLN-R-80
18.5–22 2028220-125 KLN-R-125
30 2028220-150 KLN-R-150
37 2028220-200 KLN-R-200
45 2028220-250 KLN-R-250
Table 7.13 3x200–240 V, Enclosure Types A, B, and C
1) KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
3) A6KR fuses from Ferraz Shawmut may substitute A2KR for 240 V frequency converters.
4) A50X fuses from Ferraz Shawmut may substitute A25X for 240 V frequency converters.
MG16G202
Design Guide
Recommended maximum fuse
Bussmann Bussmann
Type J Type T
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
JKS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Recommended maximum fuse
Ferraz
Ferraz
Shawmut
Shawmut
Type CC Type RK1
ATM-R-10 A2K-10-R
ATM-R-15 A2K-15-R
ATM-R-20 A2K-20-R
ATM-R-25 A2K-25-R
ATM-R-30 A2K-30-R
– A2K-50-R
– A2K-60-R
– A2K-80-R
– A2K-125-R
– A2K-150-R
– A2K-200-R
– A2K-250-R
Danfoss A/S © 08/2015 All rights reserved.
Bussmann Bussmann
Type CC Type CC
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
–
–
–
–
–
–
–
Bussmann
Littelfuse
2) JFHR2
Type JFHR2
3)
FWX-10 –
FWX-15 –
FWX-20 –
FWX-25 –
FWX-30 –
FWX-50 –
FWX-60 –
FWX-80 –
FWX-125 –
FWX-150 L25S-150
FWX-200 L25S-200
FWX-250 L25S-250
Bussmann
Type CC
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
– –
– –
– –
– –
– –
– –
– –
Ferraz
Ferraz
Shawmut
Shawmut
JFHR2 4) J
– HSJ-10
– HSJ-15
– HSJ-20
– HSJ-25
– HSJ-30
– HSJ-50
– HSJ-60
– HSJ-80
– HSJ-125
A25X-150 HSJ-150
A25X-200 HSJ-200
A25X-250 HSJ-250
