Type Code and Selection
Description Position Possible options
D options 38–39
Table 6.2 Ordering Type Code, Options

6.2 Options, Accessories, and Spare Parts

6.2.1 Ordering Numbers: Options and
Accessories
NOTICE
Options can be ordered as factory built-in options,
see ordering information.
Type Description
Miscellaneous hardware I
DC link Terminal block for DC link
connector connection on A2/A3
IP 21/4X top/ IP21/NEMA1 top + bottom A2
TYPE 1 kit
IP 21/4X top/ IP21/NEMA1 top + bottom A3
TYPE 1 kit
IP 21/4X top/ IP21/NEMA1 top + bottom B3
TYPE 1 kit
IP 21/4X top/ IP21/NEMA1 top + bottom B4
TYPE 1 kit
IP 21/4X top/ IP21/NEMA1 top + bottom C3
TYPE 1 kit
IP 21/4X top/ IP21/NEMA1 top + bottom C4
TYPE 1 kit
IP21/4X top IP21 top cover A2
IP21/4X top IP21 top cover A3
IP 21/4X top IP21 top cover B3
IP 21/4X top IP21 top cover B4
IP 21/4X top IP21 top cover C3
IP 21/4X top IP21 top cover C4
Panel Through Enclosure size A5
Mount Kit
Panel Through Enclosure size B1
Mount Kit
MG16G202
Design Guide
DX: No option
®
D0: VLT 24 V DC Supply
option MCB 107
Ordering
number
130B1064
130B1122
130B1123
130B1187
130B1189
130B1191
130B1193
130B1132
130B1133
130B1188
130B1190
130B1192
130B1194
130B1028
130B1046
Danfoss A/S © 08/2015 All rights reserved.
Type Description
Miscellaneous hardware I
Panel Through Enclosure size B2
Mount Kit
Panel Through Enclosure size C1
Mount Kit
Panel Through Enclosure size C2
Mount Kit
Screw terminal blocks for replacing
spring loaded terminals
Terminal blocks
1 pc 10-pin, 1 pc 6-pin, and 1 pc 3-
pin connectors
Back plate A5 IP55/NEMA 12
Back plate B1 IP21/IP55/NEMA 12
Back plate B2 IP21/IP55/NEMA 12
Back plate C1 IP21/IP55/NEMA 12
Back plate C2 IP21/IP55/NEMA 12
Back plate A5 IP66
Back plate B1 IP66
Back plate B2 IP66
Back plate C1 IP66
Back plate C2 IP66
LCPs and kits
LCP 102 Graphical local control panel (GLCP) 130B1107
LCP cable Separate LCP cable, 3 m
LCP kit LCP mounting kit including
graphical LCP, fasteners, 3 m cable,
and gasket
LCP kit LCP mounting kit including
numerical LCP, fasteners, and gasket
LCP kit LCP mounting kit for all LCPs
including fasteners, 3 m cable, and
gasket
LCP kit Front mounting kit, IP55/IP66
enclosures, fasteners, 8 m cable,
and gasket
LCP kit LCP mounting kit for all LCPs
including fasteners and gasket -
without cable
Table 6.3 Options and Accessories
Ordering
number
130B1047
130B1048
130B1049
130B1116
130B1098
6 6
130B3383
130B3397
130B3910
130B3911
130B3242
130B3434
130B3465
130B3468
130B3491
175Z0929
130B1113
130B1114
130B1117
130B1129
130B1170
