Danfoss VLT Refrigeration Drive FC 103 Design Manual page 133

Specifications
3x525–600 V
Bussman
Power Bussmann
n
[kW] Type J
Type RK1
1.1 KTS-R-5 JKS-5
1.5–2.2 KTS-R-10 JKS-10
3 KTS-R15 JKS-15
4 KTS-R20 JKS-20
5.5 KTS-R-25 JKS-25
7.5 KTS-R-30 JKS-30
11–15 KTS-R-35 JKS-35
18 KTS-R-45 JKS-45
22 KTS-R-50 JKS-50
30 KTS-R-60 JKS-60
37 KTS-R-80 JKS-80
45 KTS-R-100 JKS-100
55 KTS-R-125 JKS-125
75 KTS-R-150 JKS-150
90 KTS-R-175 JKS-175
Table 7.16 3x525–600 V, Enclosure Types A, B, and C
MG16G202
Design Guide
Recommended maximum fuse
Bussmann Bussmann Bussmann
Type T Type CC Type CC
JJS-6 FNQ-R-5 KTK-R-5
JJS-10 FNQ-R-10 KTK-R-10
JJS-15 FNQ-R-15 KTK-R-15
JJS-20 FNQ-R-20 KTK-R-20
JJS-25 FNQ-R-25 KTK-R-25
JJS-30 FNQ-R-30 KTK-R-30
JJS-35 – –
JJS-45 – –
JJS-50 – –
JJS-60 – –
JJS-80 – –
JJS-100 – –
JJS-125 – –
JJS-150 – –
JJS-175 – –
Danfoss A/S © 08/2015 All rights reserved.
Bussmann SIBA Littelfuse
Type CC Type RK1 Type RK1
LP-CC-5 5017906-005 KLS-R-005
LP-CC-10 5017906-010 KLS-R-010
LP-CC-15 5017906-016 KLS-R-015
LP-CC-20 5017906-020 KLS-R-020
LP-CC-25 5017906-025 KLS-R-025
LP-CC-30 5017906-030 KLS-R-030
– 5014006-040 KLS-R-035
– 5014006-050 KLS-R-045
– 5014006-050 KLS-R-050
– 5014006-063 KLS-R-060
– 5014006-080 KLS-R-075
– 5014006-100 KLS-R-100
– 2028220-125 KLS-125
– 2028220-150 KLS-150
– 2028220-200 KLS-175
Ferraz Ferraz
Shawmut Shawmut
Type RK1 J
A6K-5-R HSJ-6
A6K-10-R HSJ-10
A6K-15-R HSJ-15
A6K-20-R HSJ-20
A6K-25-R HSJ-25
A6K-30-R HSJ-30
A6K-35-R HSJ-35
A6K-45-R HSJ-45
A6K-50-R HSJ-50
A6K-60-R HSJ-60
A6K-80-R HSJ-80
A6K-100-R HSJ-100
7
A6K-125-R HSJ-125
A6K-150-R HSJ-150
A6K-175-R HSJ-175
