Danfoss VLT Refrigeration Drive FC 103 Design Manual page 67

System Integration
®
VLT PROFINET MCA 120
The PROFINET option offers connectivity to PROFINET-
based networks via the PROFINET protocol. The option is
able to handle a single connection with an actual packet
interval down to 1 ms in both directions.
•
Built-in web server for remote diagnosis and
reading out of basic frequency converter
parameters.
•
If certain warnings or alarms occur, or have
cleared again, an e-mail notification can be
configured for sending an e-mail message to 1 or
several receivers.
•
TCP/IP for easy access to frequency converter
configuration data from MCT 10 Set-up Software.
•
FTP (File Transfer Protocol) file upload and
download.
•
Support of DCP (discovery and configuration
protocol).
More options
®
VLT General Purpose I/O MCB 101
The I/O option offers an extended number of control
inputs and outputs.
•
3 digital inputs 0–24 V: Logic 0<5 V; Logic 1>10 V.
•
2 analog inputs 0–10 V: Resolution 10 bit plus
sign.
•
2 digital outputs NPN/PNP push-pull.
•
1 analog output 0/4–20 mA.
•
Spring-loaded connection.
•
Separate parameter settings.
•
Ordering numbers:
-
130B1125 uncoated.
- 130B1212 coated (Class G3/ISA
S71.04-1985).
®
VLT Relay Option MCB 105
Enables extending relay functions with 3 extra relay
outputs.
•
Maximum terminal load: AC-1 resistive load: 240
V AC, 2 A, AC-15 .
•
Inductive load @cos ф 0.4: 240 V AC, 0.2 A, DC-1.
•
Resistive load: 24 V DC, 1 A, DC-13 .
•
Inductive load: @cos ф 0.4: 24 V DC, 0.1 A.
•
Minimum terminal load: DC 5 V: 10 mA.
•
Maximum switch rate at rated load/minimum
load: 6 min-1/20 s-1.
•
Ordering numbers:
- 130B1110 uncoated.
-
130B1210 coated (Class G3/ISA
S71.04-1985).
MG16G202
Design Guide
®
VLT Analog I/O Option MCB 109
This analog input/output option is easily fitted in the
frequency converter for upgrading to advanced
performance and control using the additional inputs/
outputs. This option also upgrades the frequency converter
with a battery back-up supply for the clock built into the
frequency converter. This provides stable use of all
frequency converter clock functions as timed actions.
•
•
•
•
•
®
VLT Extended Relay Card MCB 113
The Extended Relay Card MCB 113 adds inputs/outputs to
the frequency converter for increased flexibility.
•
•
•
•
•
•
®
VLT 24 V DC Supply Option MCB 107
The option is used to connect an external DC supply to
keep the control section and any installed option active
when mains power is down.
•
•
•
•
•
•
•
Danfoss A/S © 08/2015 All rights reserved.
3 analog inputs, each configurable as both
voltage and temperature input.
Connection of 0–10 V analog signals as well as
PT1000 and NI1000 temperature inputs.
3 analog outputs each configurable as 0–10 V
outputs.
Included back-up supply for the standard clock
function in the frequency converter. The back-up
battery typically lasts for 10 years, depending on
the environment.
Ordering numbers:
- 130B1143 uncoated
- 130B1243 coated (Class G3/ISA
S71.04-1985)
7 digital inputs.
2 analog outputs.
4 SPDT relays.
Meets NAMUR recommendations.
Galvanic isolation capability.
Ordering numbers:
- 130B1164 uncoated.
-
130B1264 coated.
Input voltage range: 24 V DC ±15% (maximum 37
V in 10 s).
Maximum input current: 2.2 A.
Maximum cable length: 75 m.
Input capacitance load: <10 uF.
Power-up delay: <0.6 s.
Easy to install in frequency converters in existing
machines.
Keeps the control board and options active
during power cuts.
