Appendix - Selected Drawing...
Hole number
and
recommended
use
1 Mains
2 Motor
3 Brake/load
sharing
4 Control cable
5 Control cable
1) Tolerance ±0.2 mm
8
8
Illustration 8.34 Enclosure Size C1, IP21
Hole number and
recommended use
1
Mains
2
Motor
3
Brake/load sharing
4
Control cable
5
Control cable
6
Control cable
1) Tolerance ±0.2 mm
Illustration 8.35 Enclosure Size C2, IP21
150
VLT
Dimensions
1)
UL [in]
[mm]
2
63.3
2
63.3
1 1/2
50.2
3/4
28.4
1/2
22.5
Dimensions
1)
UL [in] [mm]
2
63.3
2
63.3
1 1/2
50.2
3/4
28.4
1/2
22.5
1/2
22.5
Danfoss A/S © 08/2015 All rights reserved.
®
Refrigeration Drive FC 103
[5]
[4]
[2]
[3]
[1]
Nearest
metric
M63
M63
M50
M25
M20
[5]
[6]
[2]
[3]
[4]
[1]
Nearest
metric
M63
M63
M50
M25
M20
M20
MG16G202
