Type Code and Selection
Parameter
Parameter 14-01 Switching Frequency
Parameter 14-55 Output Filter
Parameter 14-56 Capacitance Output Filter Not used
Parameter 14-57 Inductance Output Filter
Table 6.17 Parameter Settings for dU/dt Filter Operation

6.2.8 Common Mode Filters

Enclosure size
A and B
6 6
C1
C2, C3, C4
Table 6.18 Common Mode Filters, Ordering Numbers
Illustration 6.2 HF-CM Core
114
VLT
Setting
Higher operating switching frequency than specified by the individual filter is not
recommended.
[0] No filter
Not used
Ordering Core dimension
number
W
130B3257 60
130B7679 82.8
130B3258 102
W
w
Danfoss A/S © 08/2015 All rights reserved.
®
Refrigeration Drive FC 103
w H
43 40
57.5 45.5
69 61
d
h d
25 22.3
20.6 33
28 37
Weight
[kg]
0.25
–
1.6
