Installation

This section describes the installation of the SF 26PT speaker and includes the following
topic:
AVERTISSEMENT :
NOTE: This speaker is intended for flexible wiring connection only.

Installing the SF 26PT Speaker

The SF 26PT speaker is ideal for open ceilings. It is suspended using the
PendantConnect-2 cable that is composed of 2 steel support cables and 2 speaker wires.
Figure 2.
WARNING: Risk of personal injury or property damage. The final installation
should be able to continuously support the speaker weight. The final installation
should also be able to support any short term overloading. Since applications can
vary considerably, it is assumed that the installer will exercise good judgment when
selecting the mounting location, method, and hardware. Installation and service must
be performed by authorized personnel only.
Risque de dommages corporels ou matériels.
L'installation finale doit pouvoir supporter en permanence le poids de l'enceinte.
L'installation finale doit également supporter toute surcharge temporaire. Étant donné
la possibilité d'évolution considérable des applications, il est supposé que l'installateur
fera preuve de discernement lors de la sélection de l'emplacement, du mode, et
du matériel de montage. L'installation et la maintenance du système doivent être
exclusivement effectuées par le personnel autorisé.
Steel Cables (2)
Speaker Wires (2) —
Black (with red stripe) and Red
PendantConnect-2
Cable
Speaker
SF 26PT Speaker Assembly
SF 26PT User Guide • Installation 3
