NOTE:
• In order to ensure that the cable lock is not unintentionally unlocked, keep the
area within 2 inches of all cable locks in any direction free of any other objects.
• If cable locks need to be within 2 inches of each other they must be at the
same height.
Pipe
Steel Cable
2. See Wiring the Amplifier/Previous Speaker
6. See Wiring the Speaker
NOTE: The speaker cap will have to remain attached while wiring the speaker.
Cable locks
must be at the
same height
as each other.
Cable Lock
on page 10.
on page 11.
