Painting the Speaker Grille

The removable speaker grille can be painted using spray paint. Ensure that the spray paint
adheres to both metal and plastic.
NOTE: Extron is not responsible for any alterations to the original paint.
To paint the grille:
1.
2.
3.
4.
5.
6.
7.
Remove the grille from the speaker using the included grille hook.
Enclosure
Cloth Scrim Backing
Speaker Grille
Grille Hook
Figure 24. Removing the Speaker Grille
Remove and set aside the cloth scrim from the back side of the grille.
Peel off the Extron logo from the front of the grille.
Spray paint the front side of the grille.
NOTES:
• Apply an even coat across the entire front surface.
•
Be sure not to clog the grille holes.
Wait for the paint to dry.
Reattach the cloth scrim that was removed in step 2 to the back of the grille.
Reattach the grille to the speaker. Six small magnets secure the grille in place.
SF 26PT User Guide • Reference Information 25
