Wiring the SF 26PT Speaker Assembly

The SF 26PT speaker system includes the two SF 26PT speakers with a removable top
cap, a 30-foot length of PendantConnect-2 cable (that consists of two 30-foot lengths of
steel support cable, and a 30-foot length of speaker wire), four cable locks, grille hook, and
two removable grilles.
NOTE: Each speaker is wrapped in a protective plastic bag. Keep the speaker in this
bag as much as necessary to protect the finish of the speaker. The bag may be
disposed of once the installation is complete.
Installation requires attaching two steel cables to a suitable overhead structure, attaching
the swaged ends of the cables to a hook on the speaker, and routing the two speaker wires
to the 2-pole splicing connectors on the speaker. Follow the steps below to properly install
the speaker.
NOTE: Make sure to consult and follow local electrical and building codes when
mounting the SF 26PT.
NOTES:
• To help determine the necessary length of PendantConnect-2 cable needed, if
pre-cutting, refer to the
Pre-cutting Bulk Speaker
When using pre-cut cables as described in the
•
skip steps 3 through 8.
1. Locate a suitable permanent mounting location for the SF 26PT where the two support
cables can be securely attached.
NOTE: The structural member of the building must be able to support the complete
speaker assembly including the speaker and cap, support cables, and the
speaker grille (see the
2.
Run the speaker cable from the previous speaker/amplifier to the mounting location.
NOTE: When using pre-cut cables, as described in the
section, skip steps 3 through 8.
Reference Information section and see
Cable. Otherwise follow the steps below.
Reference Information
Warning at the beginning of the "Installation" section).
SF 26PT User Guide • Installation
