Installation in a
Suspended Ceiling
(Single Installer)
If a single installer is installing the SF 26CT speaker system, follow the steps in this section.
Topics in this section include:
•
•
•
•

Installation Considerations

WARNING: Potential risk of severe injury. Installation and service must be
AVERTISSEMENT :
•
•
•

Preparing the Installation Location

1.
2.
3.
Installation Considerations
Preparing the Installation Location
Configuring the Speaker
Mounting the Speaker
performed by authorized personnel only.
Risque potentiel de blessure grave ou de mort. L'installation
et l'entretien doivent être effectués par le personnel autorisé uniquement.
All wiring and electrical connections must conform to all applicable building codes and
local ordinances.
Installation in a plenum-rated environment requires plenum rated cable or conduit.
If using secondary support cables, the installer provides the cables.
Power down all attached devices before proceeding.
Ensure that there is sufficient clearance above the ceiling tile for the unit to be installed.
Cut a hole for the speaker. Use the provided cutout template to outline the hole to be
cut in the ceiling tile as described below.
a. Remove the ceiling tile.
b.
To find the center of the tile, use a tape measure to measure the space between
two opposite corners, and mark the half-way point.
c. Position the center hole of the cutout template directly over the
center of the tile that you marked in step 3b.
d. Using the provided cutout template, trace a circle around the
cutout template.
e. Cut out the circle traced in the ceiling tile.
f. Replace the tile in the ceiling.
SF 26CT User Guide • Installation - Single Installer 3
