Out dx,al
;-----------------------------------------------------------
Dec dx; Enable the watchdog timer function
Mov al,30h
Out dx,al
Inc dx
Mov al,01h
Out dx,al
;-----------------------------------------------------------
Dec dx; Enable the watchdog timer to be reset by mouse
Mov al,0f7h
Out dx,al
Inc dx
In al,dx
Or al,80h
Out dx,al
;-----------------------------------------------------------
Dec dx; Lock NCT6776D
Mov al,0aah
Out dx,al
4. Enable the watchdog timer to be reset by keyboard
;-----------------------------------------------------------
Mov dx,2eh; Unlock NCT6776D
Mov al,87h
Out dx,al
Out dx,al
;-----------------------------------------------------------
Mov al,07h; Select the watchdog timer registers
Out dx,al
Inc dx
Mov al,08h
Out dx,al
;-----------------------------------------------------------
Dec dx; Enable the watchdog timer function
Mov al,30h
Out dx,al
Inc dx
Mov al,01h
Out dx,al
;-----------------------------------------------------------
Dec dx; Enable the watchdog timer to be strobed reset by keyboard
Mov al,0f7h
Out dx,al
Inc dx
