1.2

Specifications

1.2.1

General

IPPC-6152A
Model
LCD Size 15"
Display Type TFT (with LED backlight)
Max.
1024 x 768
Resolution
Max. Colors 16.2 M/262 K
Viewing
160/140
Angle
Luminance
400 cd/m
Contrast
700
Ratio
Backlight
50,000 hrs
Life
13 kg (28.6lbs)
Weight
Dimensions 449.92 x 315.63 x 126.4 mm
(17.71 x 12.43 x 4.98 in)
1.2.2

Hardware

CPU
Chipset
BIOS
Memory
Storage 1
Storage 2
Network
I/O
Expansion Slots
OS
IPPC-6172A
17"
TFT (with LED backlight)
1280 x 1024
16.7 M
RGB 6 bit + Hi-FRC data
170/160
2
350 cd/m
1000
50,000 hrs
15 kg (33.04 lb)
481.93 x 355.87 x 132.5 mm
(18.97 x 14.01 x 5.22 in)
Intel® Core™ i7/i5/i3 (up to 3.1 GHz)
Intel® Q87
AMI 64 MB flash BIOS
4 x DDR3 (1600/1333 MHz) DIMM, up to 32 GB
2 x 2.5" SATA 2.0/3.0 HDDs (with Intel® RAID 0.1 function)
Supports CFast (optional)
Supports 8 x slim DVD +/- RW (optional)
2 x Gigabit Ethernet, 10/100/1000 Mbps
GbE LAN1: Intel® I217-LM
GbE LAN2: Intel® I211
1 x GPIO
2 x Reserved ports (expansion COMs)
5 x USB (1 x USB 2.0 in front panel, 4 x USB 3.0)
1 x VGA
1 x DVI
1 x DP
1 x Line Out, 1 x Mic In
1 x Keyboard, 1 x Mouse
2 x PCI (standard)
2 x PCIe x1 (optional)
Windows 7/Windows 8
3
IPPC-6192A
19"
TFT (with LED backlight)
1280 x 1024
16.7 M
RGB 6 bit + Hi-FRC data
170/160
2
350 cd/m
1000
50,000 hrs
16.6 kg (35.6 lbs)
481.93 x 384.6 x 135.5 mm
(18.97 x 15.14 x 5.33 in)
