Table B.1: Watchdog Timer Registers

Address of Register (2E) Attribute
Read/Write
87 (hex)
07 (hex)
30 (hex)
F5 (hex)
F6 (hex)
F7 (hex)
AA (hex)
IPPC-6152A/6172A/6192A User Manual
Value (2F)
and
description
Write this address to I/O address port 2E (hex)
-----
twice to unlock the NCT6776D.
write Write 08 (hex) to select register of watchdog timer.
Write 01 (hex) to enable the function of the watch-
write
dog timer. This is set as disabled by default.
Set seconds or minutes as the units for the timer.
Write 0 to bit 3: Set seconds as the counting unit.
write
[default]
Write 1 to bit 3: Set minutes the as counting unit.
0: Stop timer [default]
01 ~ FF (hex): The amount of the count, in sec-
onds or minutes, depends on the value set in reg-
ister F5 (hex). This number decides how long the
write
watchdog timer waits for strobe before generating
an interrupt or reset signal. Writing a new value to
this register can reset the timer to count with the
new value.
Bit 7: Write 1 to enable the mouse to reset the
timer, 0 to disable. [default]
Bit 6: Write 1 to enable the keyboard to reset the
timer, 0 to disable.[default]
read/write
Bit 5: Write 1 to generate a timeout signal immedi-
ately and automatically return to 0. [default = 0]
Bit 4: Read the status of the watchdog timer. 1
means the timer has "timed out".
Write this address to I/O port 2E (hex) to lock the
-----
watchdog timer 2.
