1.4
I/O Layout
B
C
D
A. Power switch
B. Mouse
C. Keyboard
D. AC In
E. COM1/2/4
COM3
F. DP
G. GPIO
H. VGA
IPPC-6152A/6172A/6192A User Manual
A
E
G
J
L
F
H I
K
(RS-232)
(RS-232 /RS-422/RS-485)
8
N
M
P
I. DVI
J. 2 x LAN
K. 4 x USB 3.0
L. Line Out
M. Mic
N. DVD ROM
O. CFast
P. USB 2.0
