- Page 1 User Manual IPPC-6152A/6172A/ 6192A 15” XGA /17” SXGA/19” SXGA TFT LCD (with LED Backlight) Industrial Panel PC with Intel® Core™ i7/i5/i3 CPU and 2 x PCI Slots...
- Page 2 The documentation and the software included with this product are copyrighted 2019 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 In such cases, users are required to correct the interference at their own expense. Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the lat- est product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you require additional assistance.
- Page 4 The equipment has obvious signs of breakage. Do not leave this equipment in an environment where the storage temperature fluctuates below -40 °C or above 85 °C as this may cause damage. The equip- ment should be stored in a controlled environment. IPPC-6152A/6172A/6192A User Manual...
- Page 5 Warning! Batteries are at risk of exploding if incorrectly replaced. Replace only with same or equivalent type as recommended by the manufacturer. Discard used batteries according to the manufacturer's instructions. IPPC-6152A/6172A/6192A User Manual...
- Page 6 IPPC-6152A/6172A/6192A User Manual...
-
Page 7: Table Of Contents
1.2.5 Environmental ................4 1.2.6 Certifications ................. 4 1.2.7 IP Rating ..................4 Dimensions ....................5 Figure 1.1 IPPC-6152A Dimensions..........5 Figure 1.2 IPPC-6172A Dimensions..........6 Figure 1.3 IPPC-6192A Dimensions..........7 I/O Layout....................8 Chapter System Setup ........9 General ....................10 2.1.1... - Page 8 Exit Menu..................53 Appendix A I/O and Connector Pin Assignments..............55 GPIO ....................... 56 Appendix B Watchdog Timer Programming ..57 Overview ....................58 Watchdog Timer Programming ............... 58 Table B.1: Watchdog Timer Registers........60 Example ....................61 IPPC-6152A/6172A/6192A User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction The IPPC-6152A/6172A/6192A is an industrial panel PC equipped with a Gen 4 Intel® Core™ i7/i5/i3 processor, high-speed DDR3 memory (up to 32 GB), and two PCI expansion slots. The processor combined with an Intel® Q87 chipset provide a platform for the Intel® AMT 9.0 vPro management support system, offering remote out-of-band manageability, improved security, and energy-efficient performance. -
Page 11: Specifications
1 x VGA 1 x DVI 1 x DP 1 x Line Out, 1 x Mic In 1 x Keyboard, 1 x Mouse 2 x PCI (standard) Expansion Slots 2 x PCIe x1 (optional) Windows 7/Windows 8 IPPC-6152A/6172A/6192A User Manual... -
Page 12: Power
IP65 rating Front Bezel Test Condition Test Configuration Test System RAM: 4 x 32 GB DDR3 Burn In 8.1 HDD: 1 x 2.5” SATA 500 GB Windows 7 (64 bit) I/O: 4 x USB 2.0, 4 x loopback IPPC-6152A/6172A/6192A User Manual... -
Page 13: Dimensions
Dimensions Figure 1.1 IPPC-6152A Dimensions IPPC-6152A/6172A/6192A User Manual... -
Page 14: Figure 1.2 Ippc-6172A Dimensions
Figure 1.2 IPPC-6172A Dimensions IPPC-6152A/6172A/6192A User Manual... -
Page 15: Figure 1.3 Ippc-6192A Dimensions
Figure 1.3 IPPC-6192A Dimensions IPPC-6152A/6172A/6192A User Manual... -
Page 16: I/O Layout
J. 2 x LAN C. Keyboard K. 4 x USB 3.0 D. AC In L. Line Out E. COM1/2/4 (RS-232) M. Mic COM3 (RS-232 /RS-422/RS-485) N. DVD ROM F. DP O. CFast G. GPIO P. USB 2.0 H. VGA IPPC-6152A/6172A/6192A User Manual... -
Page 17: Chapter 2 System Setup
Chapter System Setup... -
Page 18: General
Run the BIOS setup program to set the I/O address and IRQ, and configure the jumper settings to change the COM port mode (refer to Section 3.1.2). IPPC-6152A/6172A/6192A User Manual... -
Page 19: Usb Ports
Reserved for user configuration. See Appendix A.1 for details. 2.1.10 PCI Ports The panel PC provides two PCI ports for easy expansion. However, the dimensions of any external PCI cards must not exceed 167.65 x 96.4 x 18.7 mm (6.6 x 3.8 x 0.736 in). IPPC-6152A/6172A/6192A User Manual... -
Page 20: Memory Installation
Memory Installation Loosen the six screws and remove the rear cover. Push the lever of the memory slot outwards. Insert the memory and then return the lever to its original position. IPPC-6152A/6172A/6192A User Manual... -
Page 21: Cpu Installation
CPU Installation Remove the CPU fan. Push the CPU lever outwards. IPPC-6152A/6172A/6192A User Manual... - Page 22 Remove the CPU pin cap. Install the CP, taking note of the direction of the notched corner. IPPC-6152A/6172A/6192A User Manual...
- Page 23 Return the CPU lever to its original position. Apply thermal grease (provided in the accessory box) to the CPU. Install the CPU fan and connect the CPU fan cable. IPPC-6152A/6172A/6192A User Manual...
-
Page 24: Hdd Installation
HDD Installation Loosen the four screws on the HDD bracket. IPPC-6152A/6172A/6192A User Manual... - Page 25 Insert the HDD and tighten the affixing screws (provided in the accessory box). IPPC-6152A/6172A/6192A User Manual...
-
Page 26: Dvd Rom Installation
To install an optional DVD ROM (a DVD ROM is not provided with this product and must be purchased separately), first retrieve the DVD ROM bracket and screws from the accessory box. Place the DVD ROM onto the bracket. IPPC-6152A/6172A/6192A User Manual... - Page 27 Affix the DVD ROM in place with screws on both sides of the bracket. Remove the DVD ROM plate from the panel PC. IPPC-6152A/6172A/6192A User Manual...
- Page 28 Connect the DVD ROM to 4-pin power connector using the power adapter pro- vided in the accessory box. Plug the data cable into the DVD ROM and connect the other end to the SATA 1 port of the main board. IPPC-6152A/6172A/6192A User Manual...
-
Page 29: Cfast Riser Card Installation
Plug the data cable into the CFast module and connect the other end to the SATA4 port of the main board. Mounting Instructions IPPC-6152A/6172A/6192A supports two mount options - panel and rack mounting. 2.7.1 Panel Mounting Retrieve the four mount brackets from the accessory box. -
Page 30: Rack Mounting
2.7.2 Rack Mounting For rack mounting, users will need to order the IPPC-6152A-RMKE, IPPC-6172A- RMKE, or IPPC-6192A-RMKE mount kit. These kits support mounting on a 19” industrial rack. For detailed installation instructions, please refer to the IPPC-6152- 6172-6192_Series_Mount_Installation_Guide (EN&CH) installation guide provided with the panel PC. -
Page 31: Chapter 3 Jumper Settings And Connectors
Chapter Jumper Settings and Connectors... -
Page 32: Jumper Settings
Jumper Settings This chapter explains how to set jumpers and configure the IPPC-6152A/6172A/ 6192A panel PC. A jumper is the simplest type of electric switch. It consists of two metal pins and a small metal cap (often protected by a plastic cover) that slides over the pins to con- nect them. -
Page 33: Com3 Settings
The COM3 jumper is used to select RS-232 (default), RS-422, or RS-485. Table 3.1: COM3 Settings RS-232 RS-422 RS-485 Pin Name UART_SIN RXD485 UART_SIN RXD422 UART_SIN RXD232 DCD# SOUT COM3_DCD# COM3_SOUT COM3_TXD485N COM3_RXD485P DTR# COM3_SIN COM3_DTR# COM3_TXD485P COM3_RXD485N IPPC-6152A/6172A/6192A User Manual... -
Page 34: Clear Cmos (Jcmos1)
Remove the JCMOS1 jumper (2-3). Close JCMOS1 jumper (1-2). Power on the system. CMOS data should be cleared. Set the BIOS to default. JCMOS1 Clear RTC/CMOS Reset the register bit in RTC (short 2-3) Normal operation (short 1-2) Pin Name RTCRST# IPPC-6152A/6172A/6192A User Manual... -
Page 35: Chapter 4 Intel Chipset
Chapter Intel Chipset... -
Page 36: Overview
Overview The IPPC-6152A/6172A/6192A industrial panel PC is equipped with a CD-ROM and relevant utilities and drivers. Utilities and Drivers Intel® Chipset Software Installation Utility Path: \INF\ Available for the following operating systems: Microsoft Windows 7 Microsoft Windows 8 Dual/Triple Display Click on the icon shown in the image below. - Page 37 Select “Graphics Properties”. Click on “Display”. IPPC-6152A/6172A/6192A User Manual...
- Page 38 Click on the down arrow next to Display to access the drop down menu. Select the “Multiple Displays” option and configure the parameters. IPPC-6152A/6172A/6192A User Manual...
-
Page 39: Chapter 5 Ami Bios Setup
Chapter AMI BIOS Setup... -
Page 40: Introduction
Practice navigating through the various menus and submenus. While mov- ing around the BIOS Setup program, note that explanations appear in the Item Spe- cific Help window located to the right of each menu. This window displays the help text for the currently highlighted field. IPPC-6152A/6172A/6192A User Manual... -
Page 41: Bios Configuration
Users can select any of the items in the left frame of the screen, such as SuperIO Configuration, to access the sub menu for that item. To display the options for an Advanced BIOS Setup item, simply highlight the item using the <Arrow> keys. The Advanced BIOS Setup screen is shown below. IPPC-6152A/6172A/6192A User Manual... - Page 42 The default configuration is [Enabled]. ACPI Sleep State The default configuration is [S3 only]. Users can select other options. Lock Legacy Resources The default configuration is [Disabled]. S3 Video Repost The default configuration is [Disabled]. IPPC-6152A/6172A/6192A User Manual...
- Page 43 5.2.2.2 S5 RTC Wake Settings Wake System with Fixed Time The default configuration is [Disabled]. 5.2.2.3 CPU Configuration This item displays the CPU parameters for reference. Users can configure the CPU parameters according to their preferences. IPPC-6152A/6172A/6192A User Manual...
- Page 44 IPPC-6152A/6172A/6192A User Manual...
- Page 45 5.2.2.4 SATA Configuration This page provides a list of the SATA-enabled devices installed in or connected to the system. Users can also set the HDD mode to either IDE, AHCI, or RAID. IPPC-6152A/6172A/6192A User Manual...
- Page 46 5.2.2.5 Intel® Rapid Start Technology Intel® Rapid Start Technology The default configuration is [Disabled]. 5.2.2.6 PCH-FW Configuration This page displays ME version information. MDES BIOS Status Code The default configuration is [Disabled]. IPPC-6152A/6172A/6192A User Manual...
- Page 47 Me FW Image Re-Flash The default configuration is [Disabled]. 5.2.2.7 Intel® Anti-Theft Technology Configuration Intel® Anti-Theft Technology The default configuration is [Enabled]. Enter Intel® AT Suspend Mode The default configuration is [Disabled]. IPPC-6152A/6172A/6192A User Manual...
- Page 48 The wait time to enter AMT is set as 0 as a default. Disable ME The default configuration is [Disabled]. Users can enable this function if required. The default configuration is [Enabled]. Activate Remote Assistance Process The default configuration is [Disabled]. IPPC-6152A/6172A/6192A User Manual...
- Page 49 The default value for this parameter is [20 seconds]. The options are 10 sec, 20 sec, 30 sec, and 40 sec. Device Power-Up Delay The default configuration is [Auto]. Users can select between [Auto] and [Man- ual]. IPPC-6152A/6172A/6192A User Manual...
- Page 50 The default configuration is [Auto]. Users can set the COM1 address according to their application requirements. Serial Port 2 Configuration The default configuration is [Auto]. Users can set the COM2 address according to their application requirements. IPPC-6152A/6172A/6192A User Manual...
- Page 51 Device Mode The default configuration is [Standard Serial Port Mode]. Users can also config- ure this item as [IrDA 1.0(HP SIR) mode] or [ASKIR mode]. IPPC-6152A/6172A/6192A User Manual...
- Page 52 [Output High] or [Output Low] according to their usage requirements. Smart Fan Function The default configuration is [Enabled]. Smart Fan Mode Configuration This item is used to configure the CPU fan and system fan mode. IPPC-6152A/6172A/6192A User Manual...
- Page 53 The default configuration is [Disabled]. Users can enable this function if required. 5.2.2.11 H/W Monitor System Temperature This item shows the current temperature of the entire machine. CPU Temperature (PECI) This item shows the current temperature of the CPU. IPPC-6152A/6172A/6192A User Manual...
- Page 54 The default configuration is [Disabled]. Users can configure this item according to their usage requirements. ACPI Shutdown Temperature The default configuration is [Disabled]. Users can configure this item according to their usage requirements. 5.2.2.12 Second Super IO Configuration Serial Port 3 Configuration IPPC-6152A/6172A/6192A User Manual...
- Page 55 The default configuration is [Auto]. Users can configure the COM4 address according to their application requirements. 5.2.2.13 Serial Port Console Redirection ConsoleRedirection The default configuration is [Disabled]. Users can enable this function according to their usage requirements. IPPC-6152A/6172A/6192A User Manual...
-
Page 56: Chipset Setup
5.2.3 Chipset Setup 5.2.3.1 PCH-IO Configuration USB Configuration IPPC-6152A/6172A/6192A User Manual... - Page 57 The default configuration is [Disabled]. Users can enable this function according to their usage requirements. Restore AC Power Loss The default configuration is [Power Off]. Users can configure this function as [Power On] or [Last State] according to their usage requirements. IPPC-6152A/6172A/6192A User Manual...
- Page 58 5.2.3.2 System Agent (SA) Configuration Graphics Configuration IPPC-6152A/6172A/6192A User Manual...
- Page 59 NB PCIe Configuration PEG0-Gen X The default configuration is [GEN1]. Users can configure this as [GEN2] if required. Run-Time C7 Allowed The default configuration is [Enabled]. Enable PEG The default configuration is [Enabled]. Detect Non-Compliant Devices IPPC-6152A/6172A/6192A User Manual...
-
Page 60: Boot Setting Configuration
Quiet Boot The default configuration is [Disabled]. Boot Option #1/Boot Option #2 These items show the different hardware options. Hard Drive BBS Priorities This item allows users to set the priority for hard drive bootup. IPPC-6152A/6172A/6192A User Manual... -
Page 61: Security Setup
This item allows users to restore the default BIOS configuration. Save as User Defaults This item allows users to save the current settings as user defaults. Restore User Defaults This item allows users to restore the user default configuration. IPPC-6152A/6172A/6192A User Manual... - Page 62 IPPC-6152A/6172A/6192A User Manual...
-
Page 63: Appendix A I/O And Connector Pin Assignments
Appendix I/O and Connector Pin Assignments... -
Page 64: Gpio
GPIO0 from GP70 of SIO GPIO1 from GP71 of SIO GPIO2 from GP72 of SIO GPIO3 from GP73 of SIO GPIO4 from GP74 of SIO GPIO5 from GP75 of SIO GPIO6 from GP76 of SIO GPIO7 from GP77 of SIO IPPC-6152A/6172A/6192A User Manual... -
Page 65: Appendix B Watchdog Timer Programming
Appendix Watchdog Timer Programming... -
Page 66: Overview
Overview The IPPC-6152A/IPPC-6172A/IPPC-6192A card watchdog timer can be used to monitor the software operation and take corrective action after the predefined interval in the event of a software failure. The watchdog timer is built into the NCT6776D I/O controller and provides the follow-... - Page 67 Unlock NCT6776D Select the watchdog timer register Enable the watchdog timer function Use the watchdog timer Lock NCT6776D IPPC-6152A/6172A/6192A User Manual...
-
Page 68: Table B.1: Watchdog Timer Registers
0. [default = 0] Bit 4: Read the status of the watchdog timer. 1 means the timer has “timed out”. Write this address to I/O port 2E (hex) to lock the AA (hex) ----- watchdog timer 2. IPPC-6152A/6172A/6192A User Manual... -
Page 69: Example
Out dx,al Inc dx Mov al,10 Out dx,al ;----------------------------------------------------------- Dec dx; Lock NCT6776D Mov al,0aah Out dx,al Enable the watchdog timer and set the timeout interval as 5 minutes ;----------------------------------------------------------- Mov dx,2eh; Unlock NCT6776D Mov al,87h Out dx,al IPPC-6152A/6172A/6192A User Manual... - Page 70 Mov al,0aah Out dx,al Enable the watchdog timer to be reset by mouse ;----------------------------------------------------------- Mov dx,2eh; Unlock NCT6776D Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h; Select the watchdog timer registers Out dx,al Inc dx Mov al,08h IPPC-6152A/6172A/6192A User Manual...
- Page 71 ;----------------------------------------------------------- Dec dx; Enable the watchdog timer function Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx; Enable the watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx IPPC-6152A/6172A/6192A User Manual...
- Page 72 ;----------------------------------------------------------- Dec dx; Generate a timeout signal Mov al,0f7h Out dx,al; Write 1 to bit 5 of the F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx; Lock NCT6776D Mov al,0aah Out dx,al IPPC-6152A/6172A/6192A User Manual...
- Page 73 IPPC-6152A/6172A/6192A User Manual...
- Page 74 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
