A.1

GPIO

Pin

1

2

3

4

5

6

7

8

9

IPPC-6152A/6172A/6192A User Manual

Pin Name

GPIO0 from GP70 of SIO

GPIO1 from GP71 of SIO

GPIO2 from GP72 of SIO

GPIO3 from GP73 of SIO

GPIO4 from GP74 of SIO

GPIO5 from GP75 of SIO

GPIO6 from GP76 of SIO

GPIO7 from GP77 of SIO

GND

56
