Procedure
Compiling and downloading charts
1. Select the "Charts" hierarchy folder in the component view of SIMATIC Manager.
2. Select the Edit > Compile menu command.
3. Select the following check boxes:
– Entire program
– Generate module drivers
Download WinLC RTX
1. Select the PC station in the component view of the SIMATIC Manager.
2. Select the menu command PLC > Download.
Compiling OS
1. Select the OS hierarchy folder in the component view of SIMATIC Manager.
2. Select the Edit > Compile menu command.
3. Select the following check boxes:
– Entire OS
– With memory reset
Download OS
The OS for SIMATIC PDM MS does not have to be downloaded.
5.20

Server data and downloading of a client

Server data
Before an MS or OS/MS client is downloaded, it must be assigned the relevant OS server.
This loads the server data to the MS or MS/OS client project.
Client
MS client on an engi‐
neering station
MS client on a sepa‐
rate PC station
OS/MS client
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA
Server data (server package)
MS server OS servers
whose automation systems are being
monitored
X X
X X
Configuring the maintenance stations
5.20 Server data and downloading of a client
OS server
whose OS area is dis‐
played
-
X
