10.5 Interval Balance

The interval balance analysis is available in the Clinical, Scientific package(s).
The Interval Balance analysis (Figure 42) evaluates a balance measurement divided into
different time intervals.
The interval balance analysis shows the balance measurement divided into several
intervals, each interval displays the following:
An image of the maximum pressure values of the balance measurement present in
the interval.
The range of the time interval in seconds.
The travelled COP distance in millimeter.
The COP ellipse area in square millimeter.
The number of intervals and how the balance measurement is divided can be set
through the Divide intervals combobox, the following options are available:
Number of intervals: the balance measurement is divided into intervals of equal
duration. The number of intervals can be set in the Number of intervals spinbox,
up to a maximum of twelve intervals.
Interval duration: the intervals have a fixed duration, this interval duration can be set
in the Interval duration spinbox. The last interval can be shorter if the total
recording duration is not an exact multiple of the requested interval duration.
Manual: the user can manually manipulate the intervals through the interval marker
lines in the graphs. The following actions can be performed:
Add an interval: click on the
location in the graph. Click to add the interval.
Move an interval: click on the
marker line that needs to be moved. Click and drag the interval marker to the
desired position.
Delete an interval: click on the
marker line that needs to be removed. Click to delete the interval marker line.
RS-PRD-00562-016
Figure 42:
The interval balance analysis screen.
button and place the cursor to the desired
button and place the cursor on the interval
button and place the cursor on the interval
