RSscan footscan User Manual page 87

Figure 34:
The Dynamic recording captures the dynamic pressure distribution under
the client's feet during gait and recognizes left and right feet automatically.
The Dynamic recording stage (Figure 34) shows a large preview canvas. The timeline at
the bottom displays all feet detected during the dynamic measurement. It highlights the
selected feet in blue. Footscan 9 requires at least one foot for analysis. The D3D
analysis (Section 11) even needs two left and two right feet. The Dynamic recording
stage displays the selected feet on the right. Click and drag any of the timeline
thumbnails to modify its classification or to move it to bin to discard the feet altogether.
Footscan 9 also saves all discarded feet. You will still be able to restore
discarded feet or alter its classification after recording is finished. The Feet
Selection panel in the Analyze screen (Chapter 10) provides a timeline on
which the feet selection and classification can be modified.
®
Footscan 9 is able to automatically classify recorded feet while recording. During
recording, footscan 9 processes the data and determines whether a recorded foot is a
left or right foot.
Recorded feet can also be automatically classified as garbage. If the Feet on plate
edge option is checked, feet which were recorded on the edge of the plate are
automatically discarded to the bin. Checking the Feet without recognized zones
moves feet without recognized zones to the bin (See Section
about the anatomical zones analysis).
Click Start recording to start the dynamic recording. footscan 9 recognizes feet
walking in the gait (and opposite) direction. Finish with
with the current dynamic measurement.
Click Next to save the dynamic measurement. Click
When there is at least one successful measurement the application creates a
measurement session and navigates to the Analyze screen (Chapter 10). Otherwise it
returns to the Client screen (Chapter 8).
To prevent accidental skipping, the application guards
confirmation dialog. To disable this behavior consult the Settings dialog
(Section 6.4).
RS-PRD-00562-016
®
®
®
10.10 for more information
®
Stop recording when satisfied
Skip to discard it.
Skip with a
87
