12.7 Meta Corrections

The meta corrections panel (Figure 76) allows including an additional meta bar or meta
pad.
Meta Bar
Left/Right
Height
Lateral Edge
Lateral edge
Meta Pad
Shape
Height
RS-PRD-00562-016
enables the inclusion of a meta bar. This option is only
available if an ortho base type insole has been chosen in
the insole composition panel.
controls the height of the chosen meta bar (ranging from 1
to 3 mm in steps of 1 mm).
controls the height of the lateral edge (Standard and Low).
controls the shape of the meta pad (Teardrop and T-
shape).
controls the height of the chosen meta pad (ranging from 1
to 5 mm in steps of 1 mm).
Figure 76:
Meta Corrections.
