2.3 Install the interface box

This section applies only to interface box systems. Proceed to Section
not applicable.
Verify that the power switch on the
®
footscan interface box is in the
position
Connect the cable from the footscan
plate to the analog coaxial cable (mini-din
end). Align the positioning notches
Align the connectors in a straight line and
insert carefully. Do not use excessive
force.
Connect the analog coaxial cable (XLR
end) to the analog footscan connector on
t h e footscan
positioning key and insert until the latch
locks.
Connect the external power supply to the
®
footscan interface box
Connect the mains cable to the external
power supply and the mains.
RS-PRD-00562-016
®
® interface box. Align the
OFF
®
2.4 if
