10.17 Single Foot Timing

The single foot timing analysis (Figure 54) shows the different events and phases
during a foot roll-off for the selected left and right foot.
For each event, the time is displayed both in milliseconds and as a percentage. The
percentages are relative to the total roll-off time. The following events are shown:
Initial Foot Contact: the time when the first pressure is registrated.
Initial Metatarsal Contact: the time when a metatarsal zone becomes visible.
Initial Forefoot Contact: the time when all metatarsal zones are visible.
Heel Off: the time when there is no pressure under the heel.
Last Foot Contact: the time when there is no pressure under any zone.
For each phase, the duration is displayed both in milliseconds and as a percentage.
The following phases are shown:
Initial Contact Phase: the duration between the Initial Foot Contact event and the
Initial Metatarsal Contact event.
Forefoot Contact Phase: the duration between the Initial Metatarsal Contact event
and the Initial Forefoot Contact event.
Foot Flat Phase: the duration between the Initial Forefoot Contact event and the
Heel Off event.
Forefoot Push Off Phase: the duration between the Heel Off event and the Last
Foot Contact event.
RS-PRD-00562-016
The single foot timing analysis is available in the Clinical, Scientific
Figure 54:
The single foot timing analysis screen.
package(s).
115
