10.13 Footprint size
The Footprint size analysis (Figure 50) measures the width and height of the selected
pair of feet.
Figure 50:
The Footprint Size analysis shows the general dimensions of the current foot
selection.
The cyan lines depict the length of each of the footprints. The pink lines span the total
width of the metatarsal heads. The legends display the lengths of these lines (in cm).
Click and drag the edges of each line (marked with dots) to move them to other points
of interest. Click
Reset changes to restore the lines' default positions.
RS-PRD-00562-016
109
