axis in red). The possibilities are:
Division cross coordinates: the coordinate system is centered around the point of
intersection of the frame division cross.
Plate coordinates: the coordinate system uses the same coordinate system as
reported by the pressure plate.
The position of the frame division cross is adjustable in the Division cross position
combobox. The possibilities are:
Cop first frame: the frame division cross is placed on the COP found in the first
frame of the balance measurement.
Plate center: the frame division cross is placed in the center of the plate.
Cop average (rounded to sensors): the frame division cross is placed on the average
COP of the complete balance measurement. This average is rounded to the nearest
sensor.
Custom: the frame division cross is user defined by clicking and dragging the frame
division cross.
RS-PRD-00562-016
97
