11.5 Insole height
The insole height panel controls the the height of the D3D orthotic support. The D3D
analysis proposes the heights for the left and the right foot, it is possible to modify
these values.
The insole height can adopt to the following values:
F
: insole model for flat feet
N
: insole model for high arched feet
FN
: insole model for normal feet
F+B
: insole model for flat feet + B correction. Used for normal feet when no
model is available.
Left foot
Right foot
RS-PRD-00562-016
controls the insole height of the left foot.
controls the insole height of the right foot.
Figure 65:
Insole height.
FN
127
