12.6 Heel Corrections

Heel pad
Heel Offset
Wedge
RS-PRD-00562-016
controls the inclusion of a soft heel pad (PU soft) for fat pad
syndrome, heel spur or plantar fasciitis. The heel pad
option is only available in combination with a 6 mm EVA top
layer and only for non-cycling insoles.
controls the flat increase of the heel (ranging from 1 to 6
mm in steps of 1 mm).
controls the orientation of the heel wedge (ranging from -5
to 7 degrees in steps of 1 degree). The heel wedge can be
implemented either medially (+) or laterally (-). A zero
degree wedge indicates a neutral orientation.
Figure 75:
Heel Corrections.
137
