Service Manual
H1 Bent Axis Motors, Size 060/080/110/160/210/250 cm3

Technical specifications

General specifications

Physical properties

Physical properties
Features
maximum
Displacement
minimum
at rated speed
Theoretical flow at
max. displ.
at max. speed
Theoretical torque
at max. displacement
Theor. corner power at rated speed and max.
working pressure (∆p = 450 bar [6527 psi])
Mass moment of inertia of rotating
components
Case volume
Weight dry (Electric proportional control)
Configuration
060
29.8 kg [65.7 lb]
SAE
28.3 kg [62.4 lb]
DIN
26.9 kg [59.3 lb]
Cartridge
Mounting flange
Configuration
060
SAE ISO 3019/1
125 HL 4-bolt
DIN ISO 3019/2, B4
Pilot Ø160 mm
Cartridge 2-bolt (200 dist.)
M16
© Danfoss | August 2018
General specifications
Design
Direction of rotation
Pipe connections
Recommended installation
Unit
3 3
cm [in ]
l/min
[US gal/min]
N•m/bar
[lb•in/1000 psi]
kW [hp]
2
kg•m
2
[slug•ft ]
l [US gal]
080 110
34.8 kg [76.7 lb] 48.8 kg [107.6 lb]
34.4 kg [75.8 lb] 45.0 kg [99.2 lb]
33.0 kg [72.6 lb] 41.8 kg [92.2 lb]
080
127-4 (SAE C) 4-bolt
140 HL 4-bolt
Pilot Ø190 mm
2-bolt (224 dist.)
M20
Piston motor with variable displacement bent axis design
Bi-directional
Main pressure ports: ISO split flange boss
Remaining ports: SAE straight thread O-ring boss
Discretionary, the housing must always be filled with hydraulic fluid
060 080
60 [3.66] 80 [4.88]
12 [0.73] 16 [0.98]
216 [57] 256 [68]
270 [71] 328 [87]
0.96 [583] 1.27 [777]
266 [357] 321 [430]
0.0038 0.0062
[0.0028] [0.0046]
0.9 [0.24] 1.0 [0.26]
Size
160
61.9 kg [136.5 lb]
59.3 kg [130.7 lb]
54.7 kg [120.6 lb]
Size
110 160
152-4 (SAE-D) 4-bolt
160 HL 4-bolt 180 HL 4-bolt
Pilot Ø200 mm
2-bolt (250 dist.) M20
Size
110 160 210
110 [6.71] 160 [9.76] 210 [12.81] 250 [15.25]
22 [1.34] 32 [1.95] 42 [2.56]
319 [84] 416 [110] 504 [133]
407 [108] 528 [139] 630 [166]
1.75 [1069] 2.55 [1555] 3.34 [2038] 3.98 [2426]
396 [531] 513 [689] 609 [817]
0.0108 0.0211 0.0306
[0.0080] [0.0156] [0.0226]
1.4 [0.37] 2.7 [0.71] 2.8 [0.74]
210 250
81.0 kg [179 lb] 87.0 kg [196.2 lb]
75.0 kg [165 lb] –
– –
210
165-4 (SAE E)
200 HL 4-bolt
–
AX00000025en-US0504 | 13
250
50 [3.05]
550 [145]
700 [185]
684 [917]
0.0402
[0.0296]
4.1 [1.08]
250
–
–
