User Manual
ATEX H1 Bent Axis Variable Displacement Motors
Technical information
ATEX technical specifications
T-codes and maximum surface temperature
©
Danfoss | August 2021
The technical specifications in this chapter are supplemental for ATEX systems only. For comprehensive
technical specifications, including maximum pressure rating, maximum flow, etc. please refer to the
standard H1B Technical Information document.
Danfoss does not claim responsibility for the use of the motors in operating conditions not allowed
according to the information shown in this document and the standard H1B Technical Information
document.
Painting or coating can be an electric insulator if a thickness greater than 200 um is applied. The
thickness of the paining of original DPS paint is less than 200 um.
Gaseous environment (G)
Ambient and oil temperature
Maximum oil
Maximum ambient temperature
temperature
≤ 20 °C [64 °F]
≤ 20 °C [68 °F]
T5
≤ 40 °C [104 °F]
T5
≤ 60 °C [140 °F]
T5
≤ 80 °C [176 °F]
T4
≤ 115 °C [239 °F]
T4
Ambient oil temperature
Maximum oil
Maximum ambient temperature
temperature
≤ 20 °C [64 °F]
≤ 20 °C [68 °F]
T5
≤ 40 °C [104 °F]
T5
≤ 60 °C [140 °F]
T5
≤ 80 °C [176 °F]
T4
≤ 115 °C [239 °F]
T3
T-codes maximum surface temperature
Temperature class
T3
T4
T5
To ensure that the surface temperature will not exceed the allowed value according to the used
temperature class, it is recommended to attach a temperature sensor to the motors in the shown area on
one of the side surfaces near the maximum displacement limiter at the bottom side of the motors.
≤ 40 °C [104 °F]
T5
T5
T4
T4
T3
≤ 40 °C [104 °F]
T5
T5
T4
T4
T3
Maximum surface temperature
°C
200
135
100
≤ 60 °C [140 °F]
T5
T4
T4
T3
T3
≤ 60 °C [140 °F]
T5
T4
T4
T3
T3
[°F]
392
275
212
BC382476021584en-000102 | 7
