General Specifications
Control card, RS-485 serial communication
Terminal number
Terminal number 61
The RS-485 serial communication circuit is functionally separated from other central circuits and galvanically isolated from the
supply voltage (PELV).
Control card, USB serial communication
USB standard
USB plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB ground connection is not galvanically isolated from protection earth. Use only an isolated laptop as PC connection to
the USB connector on the frequency converter.
Relay outputs
Programmable relay outputs
Relay 01 Terminal number
1)
Max. terminal load (AC-1) on 1-3 (NC), 1-2 (NO) (Resistive load)
1)
Max. terminal load (AC-15) (Inductive load @ cosφ 0.4)
Max. terminal load (DC-1) 1) on 1-2 (NO), 1-3 (NC) (Resistive load)
1)
Max. terminal load (DC-13) (Inductive load)
Relay 02 (FC 302 only) Terminal number
Max. terminal load (AC-1) 1) on 4-5 (NO) (Resistive load)
1)
Max. terminal load (AC-15) on 4-5 (NO) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 4-5 (NO) (Resistive load)
1)
Max. terminal load (DC-13) on 4-5 (NO) (Inductive load)
Max. terminal load (AC-1) 1) on 4-6 (NC) (Resistive load)
1)
Max. terminal load (AC-15) on 4-6 (NC) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 4-6 (NC) (Resistive load)
1)
Max. terminal load (DC-13) on 4-6 (NC) (Inductive load)
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
Cable lengths and cross sections
Max. motor cable length, screened/armoured
Max. motor cable length, unscreened/unarmoured
Maximum cross section to control terminals, flexible/ rigid wire without cable end sleeves
Maximum cross section to control terminals, flexible wire with cable end sleeves
Maximum cross section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross section to control terminals
Control card performance
Scan interval
Control characteristics
Resolution of output frequency at 0-1000 Hz
Repeat accuracy of Precise start/stop (terminals 18, 19)
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open loop)
Speed control range (closed loop)
Speed accuracy (open loop)
Speed accuracy (closed loop), depending on resolution of feedback device
Torque control accuracy (speed feedback)
All control characteristics are based on a 4-pole asynchronous motor
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
®
MG34Q202 - VLT is a registered Danfoss trademark
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
1.1 (Full speed)
USB type B "device" plug
1-3 (break), 1-2 (make)
240 V AC, 0.2 A
24 V DC, 0.1 A
4-6 (break), 4-5 (make)
240 V AC, 0.2 A
24 V DC, 0.1 A
240 V AC, 0.2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 20 mA
over-voltage category III/pollution degree 2
1.5 mm
1 mm
0.5 mm
0.25 mm
1:100 of synchronous speed
1:1000 of synchronous speed
30-4000 rpm: error ±8 rpm
0-6000 rpm: error ±0.15 rpm
max error±5% of rated torque
5 5
2
240 V AC, 2 A
60 V DC, 1 A
400 V AC, 2 A
80 V DC, 2 A
240 V AC, 2 A
50 V DC, 2 A
150 m
300 m
2
/16 AWG
2
/18 AWG
2
/20 AWG
2 /24 AWG
1 ms
± 0.003 Hz
≤± 0.1 ms
≤ 2 ms
