How to Install
Terminal locations - Rectifier (F10, F11, F12 and F13)
3 3
Illustration 3.15 Terminal locations - Rectifier (Left side, front and right side view). The gland plate is 42 mm below .0 level.
1) Loadshare Terminal (-)
2) Earth ground bar
3) Loadshare Terminal (+)
20
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
239.6 [ 9.43 ]
R2/L12 91-1 S2/L22 92-1 T2/L32
160.0 [ 6.30 ]
R1/L11 91 S1/L21 92 T1/L31 93
56.6 [ 2.23 ]
0.0 [ 0.00 ]
®
MG34Q202 - VLT is a registered Danfoss trademark
U/T1 96 V/T2 97 W/T3 98
93-1
1
