How to Install
CUSTOMER
SUPPLIED 24V RET.
CUSTOMER
SUPPLIED 24V
3 3
Illustration 3.33 Diagram showing all electrical terminals with NAMUR option shown in dotted line box.
Terminal 37 is the input to be used for Safe Stop. For instructions on Safe Stop installation please refer to the section Safe Stop Instal-
lation in the Design Guide. See also sections Safe Stop and Safe Stop Installation.
1) F8/F9 = (1) set of terminals.
2) F10/F11 = (2) sets of terminals.
3) F12/F13 = (3) sets of terminals.
4) F14 = (4) sets of terminals.
50
VLT
Operating Instructions High Power
1
CONTROL CARD PIN 20
1
(TERMINAL JUMPERED TOGETHER)
1
2
3
CUSTOMER SUPPLIED
(TERMINAL JUMPERED TOGETHER)
3
3
10 MCB 113 PIN X46/1
11 MCB 113 PIN X46/3
12 MCB 113 PIN X46/5
13 MCB 113 PIN X46/7
14 MCB 113 PIN X46/9
15 MCB 113 PIN X46/11
16 MCB 113 PIN X46/13
17 MCB 113 PIN 12
18 CONTROL CARD PIN 37
30 TB08 PIN 01
31 TB08 PIN 02
32 TB08 PIN 04
33 TB08 PIN 05
34 MCB 113 PIN X47/1
35 MCB 113 PIN X47/3
36 MCB 113 PIN X47/2
37 MCB 113 PIN X47/4
38 MCB 113 PIN X47/6
39 MCB 113 PIN X47/5
40 MCB 113 PIN X47/7
41 MCB 113 PIN X47/9
42 MCB 113 PIN X47/8
50 CONTROL CARD PIN 53
51 CONTROL CARD PIN 55
60 MCB 113 PIN X45/1
61 MCB 113 PIN X45/2
62 MCB 113 PIN X45/3
63 MCB 113 PIN X45/4
90 MCB 112 PIN 1
91 MCB 112 PIN 2
TB7
MG34Q202 - VLT
® Automation Drive FC 300 12-Pulse
118 117
+ -
REGEN
TERMINALS
PILZ
TERMINALS
2
TB3 INVERTER 1
R-
R+
1
TB3 INVERTER 1
TB3 INVERTER 2
R-
2
R+
TB3 INVERTER 2
AUX FAN AUX FAN
L1 L1
L2 L2
100 101 102 103
®
is a registered Danfoss trademark
1
2
INVERTER
3
CABINET
CUSTOMER
4
CONNECTION
DETAILS
5
5
TB8
3
C14
98
W
C13
V 97
A2
96
U
FUSE
R-
81
TB4 EXTERNAL BRAKE
R+ 82
EXTERNAL BRAKE
98
W
V 97
U 96
81
EXTERNAL BRAKE
82
EXTERNAL BRAKE
98
W
97
V
96
U
81 EXTERNAL BRAKE
82 EXTERNAL BRAKE
4
W
98
97 V
96
U
81
R-
82 R+
