How to Programme
4.1.2 Initial Commissioning
The easiest way of carrying out the initial commissioning is by using the [Quick Menu] key and follow the quick set-up
procedure using LCP 102 (read table from left to right). The example applies to open loop applications.
Press
Quick
Menu
4 4
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
1-29 Automatic Motor Adaptation
(AMA)
3-02 Minimum Reference
3-03 Maximum Reference
3-41 Ramp 1 Ramp up Time
3-42 Ramp 1 Ramp Down Time
3-13 Reference Site
56
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
Q2 Quick Menu
OK Set language
OK Set Motor nameplate power
OK Set Nameplate voltage
OK Set Nameplate frequency
OK Set Nameplate current
Set Nameplate speed in RPM
OK
If terminal default is Coast
inverse it is possible to change
OK this setting to No function. No
connection to terminal 27 is
then needed for running AMA
Set desired AMA function.
OK Enable complete AMA is
recommended
Set the minimum speed of the
OK
motor shaft
Set the maximum speed of the
OK
motor shaft
Set the ramping up time with
OK reference to synchronous
motor speed, n
Set the ramping down time
OK with reference to synchronous
motor speed, n
Set the site from where the
OK
reference must work
®
