Warnings and Alarms
ALARM 82, CSIV parameter error
CSIV failed to init a parameter.
ALARM 85, Dang fail PB:
Profibus/Profisafe Error.
WARNING/ALARM 104, Mixing fan fault
The fan monitor checks that the fan is spinning at drive
power-up or whenever the mixing fan is turned on. If the
fan is not operating, then the fault is annunciated. The
mixing-fan fault can be configured as a warning or an
alarm trip by parameter 14-53 (Fan Monitor).
Troubleshooting Cycle power to the frequency converter
to determine if the warning/alarm returns.
ALARM 243, Brake IGBT
6 6
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 27. The report value in the alarm log
indicates which power module generated the alarm:
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
ALARM 244, Heatsink temperature
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 29. The report value in the alarm log
indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
110
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
ALARM 245, Heatsink sensor
This alarm is only for F Frame frequency converters. It is
equivalent to Alarm 39. The report value in the alarm log
indicates which power module generated the alarm
ALARM 246, Power card supply
This alarm is only for F Frame frequency converter. It is
equivalent to Alarm 46. The report value in the alarm log
indicates which power module generated the alarm
ALARM 69, Power card temperaturePower card
temperature
This alarm is only for F Frame frequency converter. It is
equivalent to Alarm 69. The report value in the alarm log
indicates which power module generated the alarm
®
MG34Q202 - VLT is a registered Danfoss trademark
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left intverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectifier module.
6 = right rectifier module in F14 frame size.
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes .
2 = right inverter module in F10 or F11 frame
sizes.
2 = second drive from the left inverter module in
F14 frame size.
