How to Programme
Par. Parameter description
No. #
6-7* Analog Output 3
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
6-74 Terminal X45/1 Output Timeout Preset
6-8* Analog Output 4
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
6-84 Terminal X45/3 Output Timeout Preset
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
Default value
null
0.00 %
100.00 %
0.00 %
0.00 %
null
0.00 %
100.00 %
0.00 %
0.00 %
®
MG34Q202 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
Conver- Type
sion
index
- Uint8
-2 Int16
-2 Int16
-2 N2
4 4
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
