How to Install
Terminal locations - Inverter Frame size F12 and F13
3 3
FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98
Illustration 3.13 Terminal locations - Inverter Cabinet (front, left and right side view). The gland plate is 42 mm below .0 level.
1) Earth ground bar
18
VLT ®
Operating Instructions High Power
FASTENER TORQUE: MIO 19 Nm (14 FT -LB) FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
MG34Q202 - VLT
Automation Drive FC 300 12-Pulse
1
2
3
®
is a registered Danfoss trademark
308.3 [12.14]
253.1 [9.96]
180.3 [7.10]
0.0 [0.00]
2
3
