How to Install
4
3 3
3
Illustration 3.29 Options Cabinet, frame size F9
1) Pilz Relay Terminal
2) RCD or IRM Terminal
3) Mains/6 phase
R1 S1
91-1 92-1
L1-1 L2-1
36
VLT
Operating Instructions High Power
1
CFD30J3
R/L1 91 S/L2 92 T/L3 93
R/L1 91 S/L2 92 T/L3 93
T1 R2 S2 T2
93-1 91-2 92-2 93-2
L3-1 L1-2 L2-2 L3-2
MG34Q202 - VLT
® Automation Drive FC 300 12-Pulse
2
5
6
4) Safety Relay Coil Fuse with Pilz Relay
See fuse tables for part numbers
5) Mains Fuses, (6 pieces)
See fuse tables for part numbers
6) 2 x 3-phase manual disconnect
®
is a registered Danfoss trademark
