Danfoss VLT FC 300 Operating Instructions Manual page 34

How to Install
3
7
3 3
4, 8, 9
5
6
Illustration 3.27 Inverter Cabinet, frame size F12 and F13
1) External Temperature Monitoring
2) AUX Relay
01 02
04 05
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2
5) Brake
-R +R
81 82
34
1 2
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98 U/T1 96
03
06
L1 L2
MG34Q202 - VLT
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98
6) Motor
U
96
T1
7) NAMUR Fuse. See 3.3.13 Fuses for part numbers
8) Fan Fuses. See 3.3.13 Fuses for part numbers
9) SMPS Fuses. See 3.3.13 Fuses for part numbers
®
is a registered Danfoss trademark
V W
97 98
T2 T3
