Top Panel (LEDs)

The LEDs panel provides information on the state of the components (whether they are active or
not) or on the network activity.
The LEDs for the Teldat V router are shown in the above figure. The table below contains a
description on them.
LED
Power
Alert
USB
F 6. L
IGURE
Estado Descripción
Off  not being powered through PSU
Monochrome
On  powered through PSU
Green
On  when software is running.
Monochrome
Green
Off  system is powered off.
Tricolor
