Wi-Fi
DSL
Eth WAN
Cell
Red  interface is unavailable because it's in
installation phase; it's not enabled (shutdown) or
due to auto-test failure.
Amber  idle.
Green  connected.
activity.
Red  interface down.
Bicolor
Green  interface up.
Blinking (green/red)  activity/maintenance.
Slow blinking  not connected
Monochrome
Rapid blinking  the link is being established
Green
Steady  connected
Green  connected. Blinking: connection data
Tricolor
activity.
Amber  blinking, auto-test.
Red  disconnected.
Off  system is powered off.
Tricolor
Red  interface is unavailable because it's in
installation phase; it's not enabled (shutdown) or
due to auto-test failure.
Amber  idle.
TELDAT V
– Installation Manual
I - 9
- Rapid blinking. It hasn't registered in the
network or there isn't sufficient quality to
do that.
- Slow blinking. GSM connection (GPRS).
- Steady. WCDMA (UMTS / HSDPA)
connection.
- Rapid blinking. It hasn't registered in the
network or there isn't sufficient quality to
do that.
- Slow blinking. GSM connection (GPRS).
- Steady. WCDMA (UMTS / HSDPA)
Blinking: connection data
