2.
Secure the module in position with #6-32 Phillips head screws and star washers (see
figure
"Special Considerations for Power Modules" below).
NOTE: Different countries require different power adapters. See
select a power module that is suitable for your location.
CAUTION:
provided grounding screws and star washers.
ATTENTION : Risque de décharge électrique. Afin d'assurer une mise à la terre
correcte, utilisez les fixations de mise à la terre et les rondelles en étoile fournies.
Special Considerations for Power Modules
After installing the module in the TLP Pro 725C enclosure, run the power cable or conduit to a
convenient junction box. Extron recommends the circuit be attached to a junction box that is
directly wired to the main circuit.
WARNING:
connecting the AC conduit to a junction box, and keep power off until installation is
complete.
AVERTISSEMENT : Risque de décharge électrique. Débranchez toutes les sources
d'alimentation électrique avant de connecter le conduit d'alimentation à un boîtier
d'encastrement, et gardez l'alimentation éteinte jusqu'à ce que l'installation soit complète.
WARNING:
retractors, ensure the power cable cannot get tangled in the cable retractor mechanism.
AVERTISSEMENT : Risque de décharge électrique. Si le câble d'alimentation est
installé à côté des rétracteurs, assurez vous qu'il ne puisse pas s'emmêler dans le
mécanisme du rétracteur de câbles.
ATTENTION:
All structural steps and electrical installation must be performed by qualified personnel in
•
accordance with local and national building codes and electrical codes.
Toute étape structurelle et installation électrique, doit être effectuée par un personnel
•
qualifié, conformément aux codes du bâtiment, aux codes incendie et sécurité, et aux
codes électriques, locaux et nationaux.
For units that are used in North America, only use AC power modules that are UL Listed
•
Model "Cable Cubby AC Power Module".
Pour les unités qui sont utilisées en Amérique du Nord, utilisez seulement les modules
•
d'alimentation secteur qui sont listés UL, modèle « Cable Cubby AC Power Module ».
The unit is not UL Listed if it uses any AC power module other than Model "Cable Cubby
•
AC Power Module".
L'unité n'est pas certifiée UL si elle utilise tout autre module d'alimentation secteur autre
•
que le modèle «Cable Cubby AC Power Module ».
9,
, on the previous page). This is especially important for the power modules (see
2
Risk of electric shock. To ensure proper electrical grounding, use the
Risk of electric shock. Switch off all electrical power before
Risk of electric shock. If the power cable is installed next to the
