Patented modular design for fast assembly and serviceability — AV connectivity can
•
be installed or serviced from the top of the enclosure after the enclosure is installed.
Series/2 Cable Access Enclosure design offers easy access to AV, data, and power
•
connections:
The enclosure accommodates three modules in a variety of configurations.
One or more of the modules can be a Series/2 AC or AC+USB power module. These
•
are available for US, Europe, and other major world markets. They are optional and
must be purchased separately.
One or two of the modules can be cable retraction systems, which support most AV,
•
data, and power needs. The cable retractors are optional and must be purchased
separately. Up to three retractor cables can be used with each retractor module.
Up to three modules can be connectivity bracket kits in any combination. Each bracket
•
can contain up to eight AV cables, or three Architectural Adapter Plates (AAPs).
Compatible with TeamWork Show Me Cables — Show Me cables provide convenient
•
connectivity and user input selection and control for TeamWork Collaboration Systems. Visit
the TeamWork System Builder at
collaboration environment.
Integrated side clamps secure enclosure to the furniture surface — the Cable Cubby
•
can be secured in place without additional parts or tools.
System connection status indicator — the communication LED provides visual feedback
•
if the touchpanel is not communicating with a control processor.
Automatic clock synchronization — allows the touchpanel to display the accurate time
•
and date.
Energy-saving features —
•
Light sensor adjusts screen brightness as the ambient room lighting changes.
•
Adjustable sleep timer puts the touchpanel into sleep mode.
•
Motion detector wakes the touchpanel.
•
Integrated lid switch automatically wakes the touchpanel when opened and can trigger
•
any other system function.
Manage, monitor, and control this device remotely — using GlobalViewer Enterprise
•
(GVE) Resource Management software.
Fully customizable using Extron control system software — GUI Designer combined
•
with Global Configurator Plus, Global Configurator Professional, or Global Scripter.
Supports the Extron Control App and Extron Control for Web.
•
High speed USB 2.0 port — for future expansion. This feature is not available on the NC
•
models.
JITC Certified — Successfully completed interoperability and information assurance testing
•
for use in government applications and other mission-critical environments.
www.extron.com to create a customized system for your
TLP Pro 725C Series Touchpanels • Introduction 2
