Media; Media Dimensions - CAB EOS2 Operator's Manual

8

Media

22
8.1

Media Dimensions

Figure 18
Dim. Designation
B Label width
with multi-lane labels
H Label height
- Tear-off length
- Cut length
A Label distance
C Width of liner
GE Width of endless material
GS Width of shrink tubes
DL Left margin
DR Right margin
E Label thickness
F Liner thickness
QE Thickness of endless material
QS Thickness of shrink tubes
V Label feed
•
•
Table 8
Labels
Media dimensions
Small label sizes, thin materials or strong glue can lead to limitations.
Critical applications need to be tested and cleared.
Note the bending stiffness ! Material must be flexible to follow the radius of the print roller !
Media dimensions
Endless material / Shrink tubes
Dim. in mm
10 - 116
5 - 57
5 - 1000
> 30
> 5
> 2
9 - 120
9 - 120
5 - 85
≥ 0
≥ 0
0,03 - 0,60
0,03 - 0,16
0,05 - 0,50
≤ 1,1
> 7
22
