- Page 1 Operator's Manual ER4 / ER6 / ER8 External Rewinder Made in Germany...
- Page 2 The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose - in particular the procurement of spare parts for products sold by cab - demand the previous written authorization by cab. Trademark Windows is a registered trademark of the Microsoft Corporation.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................4 Notes ................................ 4 Intended Use ............................4 Safety Instructions ............................ 5 Environment ............................. 5 Product Description ..........................6 Function ..............................6 Technical Data ............................6 Device Overview ............................7 Start-Up ..............................8 Contents of Delivery ..........................8 Connecting to Power Supply ........................ -
Page 4: Introduction
Introduction Notes Important information and instructions are designated as follows: Danger! Draws attention to an exceptionally great, imminent danger to your health or life due to hazardous voltages. Danger! Draws attention to a danger with high risk which, if not avoided, may result in death or serious injury. Warning! Draws attention to a danger with medium risk which, if not avoided, may result in death or serious injury. -
Page 5: Safety Instructions
Introduction Safety Instructions • The device may only be used in a dry environment, do not expose it to moisture (sprays of water, mists, etc.). • Do not try to manipulate or repair parts they are not described in the manuals of the external rewinder or the printer. -
Page 6: Product Description
Product Description Function The External Rewinders are peripheral devices for transfer printers of different manufacturers. During processing of large print jobs it is possible to take up and rewind large label roles independently of the printer. An adjustable guide axle ensures that the label strip is led horizontally from each printer into the rewinder. For a correct alignment of the External Rewinders with the printers of the A+- and XC-Series Adapter Kits are offered. -
Page 7: Device Overview
Product Description Device Overview Figure 1 Overview ER4/210 Figure 2 Overview ERx/300 1 Switch Winding Direction 6 Plate ER4/210 2 Rewind Axle 7 Clamp 3 Roller 8 Power Switch 4 Guide Axle 9 Power Input Module 5 Rewind Adapter 10 Plate ERx/300... -
Page 8: Start-Up
Start-Up Contents of Delivery Check the external rewinder for damages in transit and completeness. Contents of delivery: • External Rewinder • Clamp • 2 Rewind Adapters • Plate for ER4/210 or Plate for ERx/300 • Power Cable • Documentation Note! ... -
Page 9: Settings
Settings Setting the Winding Direction With the setting of the winding direction it is possible to rewind the labels inside or outside. Attention! Risk of gear defect! Switch off the device before changing the winding direction. ER4/210 ERx/300 Figure 4 Setting the winding direction ... -
Page 10: Operation
Operation Rewinding Directly onto the Rewind Axle Note! Remove the spring (2) from the rewind axle! Caution! Risk of injury by rotating parts! When switching on the rewinder starts immediately and winds until the material is tightened. 1. Loosen the screws (1) and remove the spring (2). Note! ... -
Page 11: Rewinding Onto 40 Mm (1.6 In) Cardboard Core
Operation Rewinding onto 40 mm (1.6 in) Cardboard Core Note! Ensure that the spring (1) is mounted on the rewind axle (2)! Consider that the cardboard core (3) should be about 1 mm (0.04 in) broader than the label strip Caution! Risk of injury by rotating parts! When switching on the rewinder starts immediately and winds until the material is tightened. -
Page 12: Rewinding Onto 76 Mm (3 In) Cardboard Core
Operation Rewinding onto 76 mm (3 in) Cardboard Core Note! Remove the spring from the rewind axle! Consider that the cardboard core (3) should be about 1 mm (0.04 in) broader than the label strip. Caution! Risk of injury by rotating parts! When switching on the rewinder starts immediately and winds until the material is tightened. -
Page 13: Licences
Person authorised to compile the technical file : Erwin Fascher Am Unterwege 18/20 99610 Sömmerda Signature for the producer : Sömmerda, 22.02.2016 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda Managing Director... -
Page 14: Fcc
Licences NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio frequency and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
