Advanced Earth Fault Diagnostic (AEFD),

AEFD results

Condition label Impedance Range
>=120kΩ
Good
> 60kΩ < 120kΩ
Poor
<=n 60kΩ
Fault
The Advanced Diagnostic test provides a specific impedance value, a polarity value, and a circuit
quality assessment of Good, Poor, or Fault. For more information about the Good, Poor, and
Fault condition labels, see Table 3. AEFD condition labels.
Description
Measurements of at least 120kΩ earth-to-ground pose no risk of causing an earth
fault.
Measurements between 60kΩ and 120kΩ earth-to ground do not cause an earth
trouble, but they indicate poor quality of earth fault isolation.
Investigate to prevent a future problem. Several channels that qualify as Poor can
cause an earth fault trouble at the panel that Location Search diagnostic will not
be able to isolate and find.
Measurements of less than 60kΩ cause an earth fault trouble. This circuit must be
investigated and wiring or devices need to be replaced.
Continued
Table 3. AEFD condition labels
