Checks and Preparation

This chapter explains how to check the GL800's external casing and
accessories, and how to prepare the GL800 for operation.
2.1 Checking the Outer Casing
2.2 Checking the Accessories
2.3 GL800 Part Names and Functions
2.4 Connecting the Power Cable and Turning on the Power
2.5 Connecting the Signal Input Cables
2.6 Logic Alarm Cable Connection and Functions
2.7 Attaching USB Memory
2.8 Connecting to a PC
2.9 Using the Battery Pack (Option)
2.10 Connecting the Humidity Sensor (Option)
2.11 Mounting and Removing the Terminal Unit
2.12 Mounting the Extension Terminal Base Set (B-537)
2.13 Mounting the 20 Channel Extension Terminal Set (B-538)
2.14 Precautions to Observe When Performing Measurement
2.15 Noise Countermeasures
2.16 Setting the Date and Time
CHAPTER
2
