Settings and Measurement

3.1 Window names and functions

1. Simplified message display : Displays the operation status.
2. Time/DIV display
3. Device access display
4. Key lock display
5. Remote display
6. Clock display
7. AC/battery status display
8. Waveform control display
9. Digital display
10. Quick settings
11. Alarm display
12. Pen display
3-2
1. Simplified message display
17. Data capture bar
16. Upper limit scale
15. Waveform display
14. Lower limit scale
13. File name display
: Displays the current time scale.
: Turns red when USB memory is accessed.
When the internal memory is being accessed, the MEM lamp
turns red.
: Displays the key lock status. (Yellow = Locked)
: Lit when the GL800 is in remote mode (Yellow = Remote mode)
: Displays the current date and time.
: Displays the icon when AC power is used and indicates the level
when the battery is used.
AC/battery indicator
: Displays the mode when using the SPAN/TRACE/POSITION key
to control the waveform.
: Displays the input value of each channel. Use the
the channel you want to activate (enlarged display).
The waveform of the active channel is displayed at the top.
: Displays items available for easy operation. Use the
activate the Quick setting area and the
: Displays the alarm output terminal status. (Red = Alarm
generated issued)
: Displays the position of each channel signal, trigger and
alarm range.
Trigger position
3. Device access display
4. Key lock display
5. Remote display
2. TIME/DIV
6. Clock display
12. Pen display 11. Alarm display
During AC supply operation
High
Low
Alarm range
Rising Falling Win In Win Out
Stop position
Start position
7. AC/battery status display
8. Waveform control display
9. Digital display
10. Quick settings
Mid
Few
key to change values.
key to select
key to
